LAB Z Turbo TL76 V-band 0.92 A/R Internal Wastegate (G30-900) Ball Bearing Turbo w/ Aluminum Center Housing

Application:

● Universal turbo for performance use, racing car, etc.

● Displacement : 2.0L ~ 3.5L

● Horsepower : 550 ~ 900 HP

Wheel Spec:

● Compressor Wheel : 61.7 / 76.8 mm (9 Swirling Blades / Point Mill Wheel)

● Turbine Wheel : 55 / 60 mm ( 9 Blades)

Compressor Housing:

● Inlet 4" / Outlet 2" / AR70 / Classic Outfit

Turbine Housing:

● V-band 0.92 A/R / Material : D5S

Bearing Type:

● Lab Z Ceramic Ball Bearing

Cooling:

● Oil Water Cooled System (Water cooling must be used for ball bearing type)

Flange Size:

● Flange Outlet : Inside diameter 2.87" (73 mm)；Outside diameter 3.2" (81.5 mm) / 3.53" (90 mm)

● Flange Inlet : Inside diameter 2.1" (55 mm)；Outside diameter 3" (76.2 mm)

Actuator:

● 1.1 bar spring pre-installed on adjustable actuator. (18 ways for application)

Includes:

● Install kit will be included in the package

Description:

● All the parts are new and every cartridge (CHRA) installed in each turbocharger is balanced by using Turbo Technics VSR balancing machine to ensure quality.

● CHRA balancing report will be included in the package.

*Contact us For any inquiries or special requests such as larger amount ordering

LAB Z Ball Bearing TURBO
