Arashi 3" TD05H-BIG16G-6cm2 w/ 6 Bolt TD42 Patrol Ball Bearing Billet Wheel Turbocharger Low Mount
Brand New and Complete CHRAs balanced by VSR Core-Balancing Machine from Turbo Technics.
Application	TD42 Patrol Diesel Low Mount Turbine housing can bolt up to fit factory exhaust manifold and dump pipe. Compressor housing inlet and outlet pipe needs to be modified to fit this 3.15” Cover
Arashi Item No.	NI-085648-03BB
Replacement For.	-
Turbine Wheel	TD05H
Turbine Diameter	49.2/55.8 mm(9 Blades)
Turbine A/R	41
Turbine Noozle Area	6cm2
Compressor Wheel	BIG16G (Billet)
Compressor Diameter	48.3 / 68 mm (GTX 11 Blades) We also offer 6+6 and 7+7 Blades. Please let us know if you need to change.
Compressor Housing	Inlet Anti-surge 3.15" / 80mm Outlet 2" / 50.8mm
Cooling	Water & Oil Cooled
Bearing	Dual-row ceramic ball bearing
Package Included	Gaskets and Install Kit
Flange	T3
Actuator	1.1 bar spring pre-installed on adjustable actuator.(18 ways for application)

*Contact us For any inquiries or special requests such as larger amount ordering
